Cat.5e UTP Cable copper networking cable 305 m in pull box

Name: Cat5e UTP Cable copper networking cable 305 m in pull box
Brand: Shenzhen Chengtiantai
Price: 1 USD

Brand Name : Shenzhen Chengtiantai

Model Number : Category 5e FTP LSZH Lan cable

Certification : CE,UL& ROHS

Place of Origin : Guangdong，China（Mainland）

MOQ : 100 units

Price : on request

Payment Terms : L/C, T/T

Supply Ability : 50,000 m/day

Delivery Time : 7 / 15 working days

Packaging Details : coil in box or reel

Category : 5e

Pairs Quantity : 4

Cable Type : FTP

Conductor Material : Solid Bare Copper

Conductor Gauge : 24 AWG (0.51 mm )

Jacket Material : PVC

Contact Now

Ethernet LAN Cable, Cat. 5e, 4 Pair, FTP Cable

Construction:

━ Bare copper wire insulated with High density Polyethylene(HDPE).

━ Two insulated conductors twisted together to form a pair and four such pairs laid up to form the basic unit.

━ The cable is shielded with an overall polyester aluminum foil with a 24 AWG stranded tinned copper drain wire and is jacketed with PVC.

Body Features
Performance Category	Cat 5e
Jacket Material	PVC
Cable Configuration	FTP
Conductor Material	Solid bare copper
Insulation Material	High density Polyethylene (HDPE)
CABLE CONSTRUCTIONS
Twisting	2 cores to the pair
Number of pairs	4 pairs
Conductor	Bare copper
Insulation	High density Polyethylene (HDPE)
Drain wire	Tinned copper
Screen	Aluminium Foil
Rip cord	Tinned copper
Sheath	PVC
Dimensions
Cable Length	1000 ft/305 m
Cable Weight	12.2 kg
Diameter Over Jacket	6.1 mm
Jacket Thickness	0.55 mm
Conductor Diameter(AWG)	24
Conductor Diameter	0.51 mm
Insulation Diameter	1.02 mm
Usage Conditions
Operating Temperature	0 to 60 ℃
Installation Temperature	-20 to 60 ℃
Storage Temperature	-20to 80 ℃
Bending Radius	4 x Cable Diameter

Electrical Characteristics

DC Resistance , maximum at 20˚C	9.38 ohms/100 m
DC Resistance Unbalance, maximum	5%
Mutual Capacitance	5.6 nF/100 m @ 1 kHz
Characteristic Impedance	100 ± 15 ohms (Frequency: 1-200 MHz)
Propagation delay at100 MHz (ns/100m)	<536
Delay Skew	≤35 ns
Nominal Velocity of Propagation (NVP)	69%
Operating Frequency, maximum	100 MHz

Nominal Transmission characteristics(at 20℃)

Frequency	Attenuation (Max)	PS NEXT (Min)	NEXT (Min)	PS ELFEXT (Min)	ELFEXT (Min)	TCL (Min)	EL TCL (Min)	RL (Min)
MHz	dB	dB	dB	dB/100m	dB/100m	dB	dB	dB
4	4.1	53.3	56.3	49	52	44	23	23
8	5.8	48.8	51.8	42.9	45.9	41	16.9	24.5
10	6.5	47.3	50.3	41	44	40	15	25
16	8.2	44.2	47.2	36.9	39.9	38	10.9	25
20	9.3	42.8	45.8	35	38	37	9	25
25	10.4	41.3	44.3	33	36	36	7	24.3
31.25	11.7	39.9	42.9	31.1	34.1	35.1	/	23.6
62.5	17	35.4	38.4	25.1	28.1	32	/	21.5
100	22	32.3	35.3	21	24	30	/	20.1

We manufactures a comprehensive array of wires and cables to meet diverse market needs.

Mannufacturing plant

R&D Building

Bird's eye view of the plant

Shenzhen chengtiantai cable is a leading company in china in the energy and telecom cable systems industry. With almost 35 years manufacturing experience, sales about $500 million in 2016 FY.

We have Over 350 well trained emplyees , and one own cable plant located in chengtiantai Industrial Park, Lisonglang community, Gongming office, Guangming district, Shenzhen with Lot area: 80,000 m², Building area:100,000 m² .

Manufacturing Process Of Lan cable


Core insulation	Wire twisting	wire backing twisting

Cabling	Jacking	Packing

Customer services:

Cat.5e UTP Cable copper networking cable 305 m in pull box

we supply a wide range of category 5e, category 6, category 6 A cable. If this all seems a litle too technical for you, then why not get in touch with us.

We look forward to assisting you in identifying the best products for your specific application and to answer any questions you might have.
